> Hitachi inverter (vfd) 1.5 hp, 230V, 1ø or 3ø
Hitachi inverter (vfd) 1.5 hp, 230V, 1ø or 3ø
230VAC Single Phase Input - 0.75 to 1.0 HP
230VAC Three Phase Input - 1.0 to 1.5 HP
200 to 240VAC +/- 10%, 50/60Hz
1 - 50 Hz.constant or variable torque
1 - 60 Hz.constant or variable torque
1 - 50 Hz.constant torque, 50 - 100 Hz. constant HP
1 - 60 Hz.constant torque, 60 - 120 Hz. constant HP
0.2 to 30 seconds by potentiometer adjustments
Fixed for approximately 70% starting torque
Fixed at 0.5Hz when RUN command is turned OFF
0 to 5 VDC (10 Kohm input impedance)
0 to 10 VDC (20 Kohm input impedance)
External potentiometer (0.5 to 2 Kohm)
Maintained dry contact for forward run and reverse run.
3 fixed preset speeds -5 Hz., 20 Hz., 40 Hz. selected by two maintained dry contacts
Clears fault and cuts off the output
Fixed at 1 second. Contact closure initiates.
Open collector output transistor energizes (27V, 50ma maximum) when output reaches set point.
Pulse output at run frequency.
Instantaneous over current, over voltage, under voltage, short circuit, overload
Black metal enclosure, can be modified to NEMA1
This Drive (VFD) is supplied with Potentiometer (free),
you need to wire/install to suit your application.
/documentation/Hitachi/PWE-10K.pdf
Connect the Single Phase power supply to R & T.
No other changes need to be made.
The drive can work with Single Phase as well as
Three Phase Input and give Three Phase output.
