Used champion r-70A/pl-70A 125-250 psi & 90-125 cfm
Our Asset #:KSC153 - 009 Qty available:1
USED CHAMPION R-70A/PL-70A 125-250 PSI & 90-125 CFM
Model: M224 Serial #: R7OA15613 Year: N/A
King Surplus is not making any representations, warranty of merchantability or any implied warranty of fitness for a particular purpose. For reference only:Champion-PL-Series-Brochure.pdf
* Bore Low Pressure: 6 1/4" x 2 Cylinders
* Bore High Pressure: 3 1/4" x 2 Cylinders
* Maximum Pump Speed: 890RPMs
* Minimum Pump Speed: 770RPMs
* Flywheel Grooves: 3 V Belt Grooves
* Bolt Down Dimensions: 11 1/4" Front to Back by 11 3/8" Right to Left
* Bolt Down Hole Diameter: 9/16"
Length: 33" Width: 27" Height: 38"
a. Est. Wt. each: 581LBS b. Est. pkging wt: 65 c. Est. total wt: 646
