Ritter midmark 415 exam table
Ritter Midmark 415 OB/GYN Power Chair Exam Table
(additional info can be seen here: http:// /Documents/ng/004-0014-00.pdf)
(139.7 cm x 83.8 cm x 111.7 cm)
Table Top Length (w/o foot section
extended) ................................. 54.0 in. (137.1.0 cm)
Table Top Length (w/ foot section
extended) ...................................... 66 in. (167.6 cm)
Table Top Width (w/ armrests) .......... 28 in. (71.1 cm)
Maximum width of upholstery ............. 22 in. (55.9 cm)
Overall Width ..................................... 30 in. (76.2 cm)
Seat height in chair position ................ 19 in. (48.3 cm)
Height in table position ....................... 34 in. (86.4 cm)
Maximum pelvic area height ............... 36 in. (91.4 cm)
Base Up ................................................ 9 1 seconds
Seat Up ................................................. 9 1 seconds
Weight Capacity (Maximum)............. 300 lb. (136.0 kg)
115 VAC Unit ........................... 110 - 120 VAC, 60 HZ,
230 VAC Unit ...................... 220 - 240 VAC, 50/60 HZ,
115 VAC Unit ........................................... 720 WATTS,
230 VAC Unit........................................ 1200 WATTS,
A separate (dedicated) circuit is recommended for
this chair. The chair should not be connected to an
electrical circuit with other appliances or equipment
unless the circuit is rated for the additional load.
