Mark-10 model bgi force torque gauge and SSM50 sensor
MARK-10 MODEL BGI FORCE /TORQUE GAUGE and SSM50 SENSOR
MARK-10 MODEL BGI FORCE /TORQUE GAUGE
Includes Mark-10 BGI Gauge, Torque Tension &
Compression Force Sensor Model SSM50,
AC Power Adapter and Protective Carrying Case.
* Fully interchangeable force and torque BGI force/torque sensors with "personality" modules. "Battery Life 8-10 Hours Per Charge"
* Unlimited number of sensors possible due to unique design
* Programmable default configuration for each sensor
* RS-232, Mitutoyo and analog outputs
* GCL - Gauge Control Language for full computer control
* Averaging mode for average readings over time
* External trigger for data capture and switch testing
* Programmable dual set points with outputs
* General purpose I/O for external device control
* Selectable units of measurement
* Accuracy: 0.1% of full scale 1 digit + sensor's accuracy
* Sampling rate: 65 readings/sec
* Environmental requirements: 40 F - 100 F [5 C - 45 C], <96% humidity (non-condensating)
Mark-10 Model SSM50 Inline 50 lbF Tension and Compression Sensor
Model SSM50 BGI force sensor measurement for tensile and compression test
* Capacity 50 lbF x 0.02 lbF resolution
* Capacity 25 kgF x 0.01 kgF resolution
* Capacity 250N x 0.1N resolution
* Accuracy +/- 0.15% of full scale plus 1 digit and BGI accuracy
* Sensor holds all BGI measurement configuration and calibration data
* Sensor enclosed within rugged aluminum housing for long lasting protection
* Threaded on both ends for interchangeable test accessories
* 150% of full scale safety overload
* Sensor includes a cable and connector for the BGI force / torque gage
The Digital Force Gauge is an advanced force measurement solution, with sophisticated measurement capabilities, data outputs, computer control capabilities, and a long list of features and configurable settings. [See Detailed Pictures Below]
