0.315" thick 120" w vulcan shear
0.315" Thick 120" W Vulcan SHEAR
0.315" Thick 120" Width Vulcan SHEAR
VULCAN 5/16 X 10 FT. CAPACITY
Cutting angle - 0.5-2 deg (powered)
Maximum stroke of top beam - 5.12 inches
Maximum plate holder force - 15 tons (with 17 hydraulic hold downs
Maximum cutting force - 20 tons
Range of back gauge - .200 - 29.5 inches
Overall dimension - Length - 148 inches / Width - 117 inches / Height - 86 inches
Weight of machine - 14,300 lbs
Electrical requirements - 220/480 volts 3 phase 60 cycles
Machine under power, ready to demo.
