12-channel color lcd holter recorder + holter analyzer
and you can see the Holter software performance!
Apply Demix technology, ensures the accuracy of QRS templates, includes N (Normal), V (Ventricular Ectopy), S (SVE), U (Unknown), P (Pacemaker), A (Artifact). All the templates can be combined or separated as individual beats. beats can be superimposed. Weak signal can be identified such as P wave.
VE, SVE, aberrant beats, V-Tach, V-Pair, V-Bigeminy, Tri-geminy etc.
HRT is the most powerful ECG-related risk predictor for assessing the death risk following myocardial infarction. The predictive value is comparable with that of the LVEF.
Unique pacemaker analysis is suitable for various models i.e. AAI, VVI, DDD, DDR pacemakers.
* HRV (Heart Rate Variability) Analysis
Time domain and Spectral domain HRV analysis, superlower HRV analysis
Heart Rate Variability is analyzed in both Time Domain and Frequency. The top of the HRV display shows the Poincare-Lorenz scatter plots. The lower left shows the Frequency power graph. The range boundaries for LF, LF and HF can be adjusted. The lower right shows the Time Domain histogram. Day and night times can be entered for Sleep Apnea and for A-Fib.
* Atrial Fibrillation and Atrial Flutter Analysis
Atrial Fibrillation is very important for the cardiologist concern. Holter ECG is an excellent test to detect transient A-Fib.
* OSAS (Obstructive Sleep Apnea Syndrome) Analysis
Using Holter test to detect the OSAS earlier and cost-saving.
ST analysis trends, form and support report, identify ischemia location.
* TWA (T-wave alterans) Analysis
Unknown for the past 40 years, T-Wave Alternans (TWA) in excess of 20 micro-volts have been in Holter recordings but have been undetected. TWA is a strong predictor of V-Tach and other serious cardiac abnormalities. It takes less than 10-seconds to do a complete 24-hour TWA analysis.
You can check for TWA anywhere in teh 24-hour ECG file. Not only can you detect TWA in the ECG file, this software lets you view the ECG showing the actual TWA, so that you can verify and validate the presence of real TWA.
The TWA algorithm detects two modes of TWA. Mode 1 is the beat-to-beat change in T-Wave amplitudes exceeding 20 micro-volts, as shown in the adjacent picture. Mode 2 is the gradual up and down changes of T-wave amplitudes over a series of several beats. .
12-lead Color LCD Holter recorder
Compact size, light weight
Fully programmable, high Fidelity
Channel: 10 digital recording channels for 12-lead
Resolution: 12 bit sampling
Frequency response: 0.05-60Hz
Recording time: 24 hours, full disclosure, no data compression, 12-lead ECG
Storage: 2G built-in flash memory
LCD display: ECG waveform and lead number
Weight: 75 grams (battery not included)
Lead: 10 wire patient cable (I, II, III, aVR, aVL, aVF, V1~V6)
1. Holter software CD with dongle key: 1 set
2. 12-channel Holter recorder: 1 unit
3. 10-lead Holter lead wire: 1 set
