Welder power cable adapter for 4-3 pin 230 volt plug
Power Adapter - NEMA 6.50P To NEMA 14-50R
Power Adapter - NEMA 6.50P To NEMA 14-50R (Full KVA)
Perfect to adapt your 230 volt welder or plasma cutter to the 230 volt "Full KVA" receptacle on your engine driven welder.
Rated for 230 volts at 50 amps, adpater comes complete with 4' 8/3 pigtail with NEMA 6.50 recptacle and NEMA 14-50 plug.
Fits Miller Bobcat 225G, Miller Bobcat 225 G Plus , Miller Bobcat 225 , Miller Bobcat 250, Miller Bobcat D, Miller Trailblazer 301 , Miller trailblazer 302, Miller Trailblazer 301D , Hobart Champion 10000, Lincoln Gas Drive welders with a large 4 pin plug for the 230 volt plug that looks like the picture
(THIS IS NOT A DRYER PLUG APPLICATION)
Insulated and jacketed to meet UL and CSA requirements.
Ampacity - A measure of the current carrying capacity of a conductor, in amps. It is important not to exceed the ampacity of a given conductor to avoid damage to the conductor.
Copper Rod - The first component in drawing copper conductors, commonly available as 5/16" rod.
Gauge - Refers to the copper conductor size, according to the American Wire Gauge, based on the conductor's circular mil area. Gauge numbers decrease as wire size increases, e.g. #8 is smaller than #6, etc.
Jacket - Refers to the insulation on the copper conductor.
NEMA - National Electrical Manufacturer's Association, the leading trade association in the US representing the interests of electroindustry manufacturers of products used in the generation, transmission and distribution, control, and end-use of electricity.
SAE - Society of Automotive Engineers, dedicated to advancing the engineering of mobility systems. SAE maintains technical standards for automotive engineering.
