Nortrac epa-iv tractor w/ag tires 60IN rough cut mower
NorTrac EPA-IV Tractor w/Ag Tires 60in Rough Cut Mower
Tough labor doesnt have to be tough on you. Superior plowing and hauling with power steering and 2-stage clutch with live PTO. 4 wheel drive. 540 and 1000 RPM PTO. Three cylinder liquid-cooled diesel. Control panel allows you to monitor fuel, oil pressure, hours and Amps. Comes with a 3-point category 1 hitch and canopy. Mower includes chain guard. Min. Operating Weight (lbs. (kg)): 2,734 (1,240), Wheel Base (in. (mm)): 64.9 (1,650), Wheel Tread Width - Front (in. (mm)): 41.3 (1,050), Wheel Tread Width - Rear (in. (mm)): 41.3 (1,050), Front Axle Ground Clearance (in. (mm)): 11.6 (295), Tires - Front: 6.00-16, Tire Inflation - Front (PSI): 26 to 29, Tires - Rear: 9.5-24 (turf 11.2-20), Tire Inflation in Field - Rear (PSI): 15.5 to 17.5, Tire Inflation in Transportation - Rear (PSI): 17.5 to 20, Turning Radius (in.): 104, Rated Traction Force (lbs.): 7,056N/1,556, Nominal Speed - Forward 1st (MPH (KM/H)): 1.0 (1.62), Nominal Speed - Forward 2nd (MPH (KM/H)): 2.0 (3.21), Nominal Speed - Forward 3rd (MPH (KM/H)): 3.3 (5.35), Nominal Speed - Forward 4th (MPH (KM/H)): 4.7 (7.51), Nominal Speed - Forward 5th (MPH (KM/H)): 9.2 (14.83), Nominal Speed - Forward 6th (MPH (KM/H)): 15.4 (24.75), Nominal Speed - Reverse 1st (MPH (KM/H)): 0.8 (1.29), Nominal Speed - Reverse 2nd (MPH (KM/H)): 3.7 (5.96), PTO Speed (RPM): 540/1,000, PTO Power (HP): 23.75, 3-Pt. Hitch Type: Category 1, Clutch: 2-Stage, Lift Capacity (lbs.): 875, Power Steering Pump Pressure (PSI): 2,810, Power Steering Pump Volume (GPM): 8.62, Engine Type: Three cylinder, vertical, water-cooled, 4-stroke, Engine Displacement (CI): 93.47, Rated Power (HP): 25, Rated RPM: 2,300/2,350, Fuel Capacity (gal.): 5.81, Engine Oil (gal. (qt.)): 1.59 (6.36), Front Drive Axle (gal. (qt.)): 1.19 (4.76), Transmission (gal. (qt.)): 3.7 (14.8), Hydraulics/Category 1 Hitch (gal. (qt.)): 2.38 (9.52), Radiator (gal. (qt.)): 2.64 (10.56)
