> New fluke 123 scopemeter - ** ** - msrp $1,385
New fluke 123 scopemeter - ** ** - msrp $1,385
Fluke 123 Industrial ScopeMeter
If needed we can Calibrate for an additional $74.99 a $169.99 service
* BB120 Shielded BNC adapter
* PM 8907 Battery Charger/Line Voltage Adapter
* STL120 Shielded Test Lead Set
The compact ScopeMeter 120 Series is the rugged solution for industrial troubleshooting and installation applications. It s a truly integrated test tool, with oscilloscope, multimeter and paperless recorder in one affordable, easy-to-use instrument. Find fast answers to problems in machinery, instrumentation, control and power systems.
In today s complex systems, a meter measurement just doesn t give enough detail to determine the cause of a fault. Signal anomalies, dropouts and glitches that might cause a machine to go down are best displayed with an oscilloscope. The ScopeMeter 124 and 123 meet today s need of simultaneously measuring and checking waveforms. The unique Connect-and-View triggering automatically displays stable waveforms of virtually any signal. It really is as easy as one-two-three A three-in-one tool
The confidence to do a better job
Up to seven hours of battery operation frees you from mains outlets for true on-the-move working. The handheld format and the weight of just 1.2 kg make the instrument easy to carry and to fit comfortably in your hand. The rugged and drip proof case assures long life and reliable operation in the harshest industrial environments. (See technical specifications for details on battery life.)
Floating measurements, safety certified
While conventional oscilloscopes can only make measurements referenced to power line ground, the Fluke 120 Series makes floating measurements so there s no risk of an accidental ground short circuit when making a connection. The Fluke ScopeMeter 120 Series test tools and the included shielded test leads are safety certified for measurements on 600 V CAT III industrial power systems. Using the VPS40 probe, measurements up to 1000 V CAT II are fully supported. Via the optically isolated RS-232 interface, the ScopeMeter 120 can be safely connected to a printer for direct print-out or to a PC for later analysis and documentation using FlukeView Software.
Max. equivalent time sample rate
Fluke 124: 10 ns/div 1 min/div.
Fluke 123: 20 ns/div 1 min/div.
Connect-and-View , Free run, Single Shot, Edge, Video
5000 counts, Volts, Amps, Ohms, Continuity, Diode, Temp
600 V CAT III (instrument and included accessories)
Adapter / battery-charger included
Using optional Optically Isolated RS-232 adapter / cable
