11" swg 18" cc hardinge hlv-em precision engine lathe,
11" Swg 18" cc Hardinge HLV-EM PRECISION ENGINE LATHE,
11" Swing 18" Centers Hardinge HLV-EM PRECISION ENGINE LATHE, Inch/Metric,Vari-Speed,5C-Collet Close
HARDINGE SUPER PRECISION TOOL ROOM LATHE
MODEL HLV-H-EM, S/N: HLV-H-14664-T, NEW: 1994
SPINDLE CONSTRUCTION ................. HARDINGE BALL BEARING
SPINDLE NOSE ......................... HARDINGE TAPER
VARIABLE SPINDLE SPEEDS .............. 125-3,000 R.P.M.
HOLE THROUGH SPINDLE ................. 1-1/4"
SWING OVER BED ....................... 11"
SWING OVER CARRIAGE .................. 9"
SWING OVER CROSS SLIDE ............... 6"
DISTANCE BETWEEN CENTERS ............. 18"
COMPOUND SLIDE TRAVEL ................ 3"
CARRIAGE POWER FEED RANGE ............ 5/16 - 7 I.P.M.
CROSS SLIDE POWER FEED RANGE ......... 3/16 - 4 I.P.M.
TAILSTOCK SPINDLE DIAMETER ........... 1-3/8"
TAILSTOCK SPINDLE TAPER .............. #2 MT
INCH THREADING RANGE IN GEARBOX (36) . 11-108 T.P.I.
METRIC THREADING RANGE IN GEARBOX (36) 0.275 - 2.7 MM
- DUAL GEARBOX FOR PRECISION ENGLISH OR METRIC THREAD CUTTING
- DUAL READING INCH/METRIC DIAL FOR COMPOUND AND TAILSTOCK
- ACU-RITE III TWO-AXIS DIGITAL READOUT
- BALL BEARING QUICK ACTING 5C COLLET CLOSER
WITH (60) ASSORTED SIZE TYPE 5C COLLETS
- HEAVY DUTY FULL BEARING TAILSTOCK WITH (1) LIVE CENTER
- (2) ADJUSTABLE LONGITUDINAL CARRIAGE STOPS
- SELF-CONTAINED COOLANT SYSTEM WITH 1/6 H.P. COOLANT PUMP MOTOR
- .5 - 1 H.P. 3/60/460 VOLT TWO-SPEED MAIN
DRIVE MOTOR AND ELECTRICAL CONTROLS
