New spectralert sensor outdoor speaker strobe red spsrk
Spectralert System Sensor Outdoor Speaker Strobe Red 12/24V (P/N Spsrk)
* Electrical Compatibility With Existing Spectralert Products
* Shorting Spring On Mounting Plate Tests Continuity Before Installation
* Rotary Switch Simplifies Field Selection Of Speaker Voltage (25 And 70.7 Vrms) And Power Settings (1/4, 1/2, 1 And 2 Watts)
* Ceiling And Wall-Mount Application
* Universal Mounting Plate For Wall- And Ceiling-Mount Units
* Weatherproof Per Nema 4X, Ip56
* Compatible With System Sensor Synchronization Protocol
* Automatic Selection Of 12- Or 24-Volt Operation At 15 And 15/75 Candela
* Field-Selectable Candela Settings On Wall And Ceiling Units
* Voltage: 25 Volts Or 70.7 Volts (Nominal)
* Candela: Selectable Candela (15, 15/75, 30, 75, 95, 100, 115 Cd)
* Operating Voltage Range: 8 To 17.5 V (12V Nominal) Or 16 To 33 V (24 Nominal)
* Operating Voltage Range With Mdl: 9 To 17.5 V (12V Nominal) Or 17 To 33 V (24 Nominal)
* Dc Max. Operating Current - Strobe: (See Data Sheet For Complete Current Draw Information)
* Fwr Max. Operating Current - Strobe: (See Data Sheet For Complete Current Draw Information)
* Power: 1/4, 1/2, 1, 2 Watts
* Frequency Range: 400 To 4000 Hz
* Operating Temperature: -40F To 151F (-40C To 66C)
skuMS-783863034282 dhaysom 4/20/2010 dhaysom 4/20/2010 CS: 74-1004020168 (C88), 74-1004020162 (C30), 74-1004020159 (C88), 74-1004020165 (C76)
