Icom F2721D P25 digital uhf 45W mobile two way radio
BRAND NEW ICOM F2721D 02, FULL P25 DIGITAL RADIO
UHF 450-512 MHz (UHF 400-470 MHz Also Available (F-2721D 01))
Project 25 (P25) Digital Features
APCO Project 25 (P25) compliant. The mixed mode scan allows you to detect and receive both analog FM and P25 digital modes.
Compatible with both analog FM mode and P25 digital mode. Program digital and/or analog FM modes per channel. The mixed mode scan allows you to detect and receive both analog FM and P25 digital modes and to transmit either mode depending on programming.
AES/DES digital encryption activation software
Secure encryption with DES and AES accordingly when activated with EX-2785 J02 (for DES) and EX-2785 J03 (for AES) activation software.
With the optional remote control kit, RMK-2 and separation cable, the front panel of the radio can be detached from the main unit. It allows you flexible installation even in limited installation space. Separation cable length is selectable from 1.9, 3.0 and 8.0m.
Dot matrix, multi-function LCD
Using a high contrast LCD, shows operating channels, tone and other settings clearly under nearly any lighting conditions. With a dot matrix display, upper and lower case characters can be easily distinguished. In addition, you can change the display setting to show one line and 12 characters, or two lines and 24 characters via programming.
Heavy-duty microphone, HM-148
The new heavy-duty hand microphone, HM-148, uses a dynamic design that is made to handle punishment. The oversized dimensions allow for easy use with gloves on. And the curl cord can be easily replaced by simply opening the case easy maintenance for long term use.
With heavy-duty construction that's built to last. Incorporates a 4W speaker in an impact resistant polycarbonate front panel for crisp clear audio, and has a backlit 10-keypad for extended operation. The 10-keypad version is supplied with an external speaker.
Built-in versatile tone signaling
Multiple 2-Tone, Multiple 5-Tone
Encode or decode up to 10 2-Tone, 8 5-Tone codes on a single memory channel. This is perfect for professionals who require multiple district paging on one channel. When a matched tone is received, the following items are programmable for each code.
The following selective calling and ANI features are available with the built-in MDC signaling.
Emergency, emergency mic monitoring
256 memory channels, 32 zones
Up to 256 memory channels can be divided into 32 memory zones, and allows you quick access to the intended channel.
The tactical group function allows you to copy memory channels to the tactical zone (zone 32) and dynamically regroup memory channels. Using the optional zone copy cable, memory channels in the tactical zone can be transferred from a master radio to other radios.
Built-in inversion type voice scrambler
Includes a built-in inversion type voice scrambler. When a more secure system is required, the optional voice scrambler unit UT-109 or UT-110 is available.
* These voice scrambler functions are not available in digital mode.
Radio stun/kill and Power-on password function
The radio stun/kill functions disable a lost or stolen radio over the air, eliminating security threats from undesired listeners. The power-on password prevents unauthorized people turning on the radio.
Public Address (PA) and RX speaker functions
When an external loud speaker is connected with the radio, you can speak through the radio s microphone. The RX speaker function allows you to relay the received audio over the loud speaker.
Microphone hanger action programmable (Scan, monitor, priority channel)
Optional OPC-617 D-SUB 9 pin connector for dimmer control, modem connection
D-SUB 25 pin connector for future PC connection
Built-in audio compander (Analog mode only)
Wide frequency coverage (400-470 or 450-512MHz)
PC programming capability
HM-148 Heavy Duty Hand Microphone
Dimensions 6-7/8" W x 1-25/32" H x 6-11/16" D, 3.3 Pounds.
