Mains electric model motor 230VAC 2711RPM 41W 0.05HP
* Spindle length 130mm end to end. Spindle diameter 6mm plain end (12mm length), 11mm rubber sleeved end.
* Frame fixings 34.5mm centres (M4 thread). Frame dimension (excluding spindles) 70mm x 70mm x 90mm
* Capacitor between 3uF and 5uF with 400V rating connected between blue and black leads.
* Connect mains to brown and either blue or black depending on desired direction of rotation
