Xeltek superpro 501S programmer reliable brand
Detail Specifications:
* Supports 23,920 IC devices from 155 manufacturers and continuing.
* Programs devices with Vcc as low as 1.2V.
* Ultra fast programming speed: Programs and verifies 64 Mb NOR FLASH memory in 11.3 seconds.
* Built with 48 universal pin-drivers for support of today s most complex devices. Universal and device independent socket adapters are available for various packages.
* The programmer operates in either PC hosted mode or stand-alone mode.
* Under PC hosted mode, a PC controls the programmer via a high-speed USB2.0 connection to program a chip.
* Under stand-alone mode, the user controls the programmer via 20-characters, 4-line LCD display with 6-KEY keypad. A CF (compact flash) card stores the project files. In stand-alone mode, the user can operate multiple units to construct a concurrent multiprogramming system.
* ISP/ICP programming capability through optional ISP/ICP adapter.
* Only IC manufacturer approved programming algorithms provide high reliability. Vcc verification at (+5%~-5%) and (10%~-10%) enhances programming reliability.
* Provides over-current and over-voltage protection for safety of the chip and programmer hardware.
* Compatible with Windows Vista and Windows XP
* Includes the following advanced and powerful software functions:
* Chip operation starts immediately upon proper chip insertion in Production Mode.
* The Project function simplifies processes such as device selection, file loading, device configuration setting, program option, and batch file setting into one step.
* Password protection provides security for project files and production volume control.
* The Batch command combines device operations like program, verify, security into a single command at any sequence.
* A Log file provides quality tracking.
Hardware & Electrical Specifications
* Devices Supported: EPROM, Paged EPROM, Parallel and Serial EEPROM, FPGA Configuration PROM, FLASH memory (NOR), BPROM, NVRAM, SPLD, CPLD, EPLD, Firmware HUB, Microcontroller, MCU, Standard Logic
* Package: DIP, SDIP, PLCC, JLCC, SOIC, QFP, TQFP, PQFP, VQFP, TSOP, SOP, TSOPII, PSOP, TSSOP, SON, EBGA, FBGA, VFBGA, uBGA, CSP, SCSP,
* PC interface: USB2.0 (High speed)
* Stand-alone memory: Compact FLASH Card
* Power Supply: Input AC 100-240V, 50/60HZ; Output DC 12V/2A power consumption: 15W
* Main unit: Dimensions 178(L) * 130(W) * 40(h) mm;
* Package: Dimensions 320(L) * 300(W) * 85(H) mm; Weight 4 lbs (1.8Kg)
* SuperPro 501S Programmer with a DIP48 Adapter
* XELTEK updates software and device algorithm regularly.
* View the latest Device List.
* Download the current software version free of charge at Download Center.
* Adapter in various packages
