Secure-tech #hc-0828 50 circuit i/o tester w/cables
FUNCTIONAL DESCRIPTION: The Secure-Tech Model #HC-0828 50-Circuit I/O Tester provides a convenient means to simultaneously test and monitor Fifty (50) separate 12vdc sinking Input and/or Output circuits.
Each circuit has a status LED to monitor Inputs and an On-Off switch to generate Outputs to the circuits under test. A red LED indicates when the circuit is low. A switch is provided to ground each circuit.
Tester is specifically designed to interface to, and test, Secure-Tech brand Detention Control Systems and Modules.
Tester Kit includes two (2) interface cables designed to connect to all major Secure-Tech brand communications and control modules and system control cables.
CONNECTORS: 12vdc Power supply conductors terminate to a compression type screw terminal strip, sized for 22 to 14 AWG stranded conductors. Two 50-conductor ribbons are provided to interface with the various Secure-Tech modules, .
Connectors are provided to test 10, 16, 26, 40 and 50 pin male "ribbon" type interfaces, as well as male and female 25-pair Amphenol "CHAMP" type 25-pair cables
