Clausing 100 atlas 4800 12" lathe operating/part manual
This is a reproduction, not a photocopy, of an original Atlas 4800 series and a Clausing 100 Mk. 3a 12 Inch Lathe Manual. This manual contains information on setup, lubrication, maintenance, and controls as well as a complete parts list and exploded views and adjustments.
One other thing is that Clausing made significant changes to the 100 series during it's production run. Below is the gear box and headstock covered in this manual. If you have the V shaped gearbox, this manual should cover your lathe. The gearbox looked significantly different, if it was there at all, on older models.
Mounting and Leveling...............................3
Lubrication.........................................6
Maintenance and Controls............................7
Setting up for Threads and Feeds....................9
Adjustments........................................10
Repair Parts.......................................13
Numerical Parts List...............................21
