2.4GHZ 4CH cctv wireless receiver 2P 24 ir led camera
New 2.4GHz Security System Kit, 100m Transmission Distance, 4Channel Remote Wireless Receiver and 2pcs 2.4GHz, OV Image Sensor Chip, 24 IR LED, 15m Night Vision Distance, Security CCTV Wireless CMOS Color Audio Video Cameras, 1.0Lux Minimum Illumination (WRC810-706)
-10 ~ +50(Degree C) / +14 ~ +122(Degree F)
-20 ~ +60(Degree C) / -4 ~ +140(Degree F)
This is a set of clear and remote Wireless supervision system.
The appearance of the Receiver is beautiful and the Channels of the two Cameras can be changed by hand or automatically.
The Camera has the function of backlight compensation, automatic white balance and so on.
It has 24 IR LED, when the illumination is below 2 ~ 4 Lux, the infrared will open automatically and can reach the best night vision effect. The supervised picture is clear and the color is bright. It is suitable for the surveillance of residence area, office, supermarket, hotel, warehouse, hospital, etc.
(2.4GHz) Wireless Infrared night vision Camera.
Infrared night vision CCD Wireless Camera with 15m night vision range.
4 Channel Receiver work with 2 Cameras.
380 TV Line Horizontal Definition.
100m transmission distance without block.
Built-in Microphone in Camera enables Audio Monitoring.
Put the Camera in the place where need to monitor.
Insert power Adapter, the DC Output Plug of power Adapter in the power Input jack of the Receiver.
Use the AV Cable to connect one Channel of Audio and Video Input plugs of the TV set or Monitor.
Press the off/on key of the Remote Control, or press the Channel key of the Receiver and open the power Adapter of the Receiver. The Receiver will acquiesce the Channel 1 after opening.
Press the Channel key (marked No.1, 2, 3 and 4) of the remote control and make the Frequency of the Receiver corresponding to the transmitter Frequency of the Receiver.
Can see the Video and listen to the voice through the television or monitor, adjust the place of the Camera, aiming at the monitoring object then can make the valid monitor.
Press the ON/OFF key of the remote control, or press the Channel button on the Receiver for 3 seconds to turn off the power of the Receiver.
The Problems And The Solutions :
The indicator of the Channel display window is not lighting. Check whether the socket of the power Adapter works well or not, and make sure the power switch is turning on.
The Receiver cannot receive picture or the picture-received flashes.
Please check whether the Wireless Camera have already put through the power.
Whether the distance between Wireless Camera and Receiver is too far or whether there is Electromagnetic shielding Barrier between Wireless Camera and Receiver (eg: Building of steel structure will make much hindrance to transmitting signal).
In the Range of Receiving, Don't make two Wireless Cameras with the same Frequency work at the same time, otherwise they will cause interfering.
When the transmitting Cameras of different Frequency work at the same time, the distance between the Cameras should be kept about or over 2 meters, otherwise receiving will be interfered.
If there are high-power transmission signals with the same Frequency and Car-mounted Radio working around, they will cause.
1 x 2.4GHz 4Channel Remote Wireless AV Receiver
2 x 2.4GHz Vimicro 0702 Vision 24 LED IR Day&Night Security CCTV Wireless CMOS Color AV Camera
1 x DC12V Adapter for Receiver
