Wolhaupter upa-4 boring and facing head set, #40 mmt
WOLHAUPTER UPA-4 BORING AND FACING HEAD SET, #40 MMT
WOLHAUPTER BORING AND FACING HEAD SET,
TAPER OF SHANK ..................... #40 MMT
MAXIMUM FACING AND BORING RANGE .... 15.75"
STROKE OF SLIDE .................... 2.05"
(12) AUTOMATIC FEED STEPS .......... .0008 TO .0094 I.P.R.
GRADUATION OF QUICK-SETTING SCREW CORRESPONDS TO A
SLIDE FEED OF .04" (EQUALS) ........ .08" ON DIAMETER
REVOLUTION OF QUICK-SETTING SCREW CORRESPONDS TO A
SLIDE FEED OF .12" (EQUALS) ........ .24" ON DIAMETER
GRADUATION OF FINE-SETTING SCREW CORRESPONDS TO A
SLIDE FEED OF .00025" (EQUALS) ..... .0005" ON DIAMETER
REVOLUTION OF FINE-SETTING SCREW CORRESPONDS TO A
SLIDE FEED OF .008" (EQUALS) ....... .016" ON DIAMETER
MAXIMUM SPEED ...................... 700 R.P.M.
MAXIMUM RECOMMENDED H.P. ........... 7 H.P.
APPROXIMATE WEIGHT: ................35 LBS.
ORIGINAL WOOD BOX WITH BORING BARS AND HOLDERS, ETC. AS
SHOWN IN ACTUAL PHOTOS - LOOKS LIKE CLOSE TO THE COMPLETE
SET ORIGINALLY PROVIDED WITH THE UNIT.
ORIGINAL WOHLHAUPTER USER'S MANUAL
