> Emtek model 520 oscilloscope 20 mhz
Emtek model 520 oscilloscope 20 mhz
Includes V/Resistor, 30 VDC P/S w/CT,2xCircuitmate DMM
BERCO Variable Resistor 439 Ohms/1.2 Amp
Monash Uni. Designed 0 to 30 VDC 1 Amp. with Centre Tap
Please remember to set the appropriate range when measuring voltage, resistance or current.
Note: DM10 (on your left) has maximum input current of 200mA only while DM15B can take 2A. Use the Fluke if you need to measure higher current. Using these two multimeters should be straight forward, select the function of measurement turning the dial into a desired selection.
Note:One of the Circuitmate, that is the DM15B, there is an AC/DC switch on the top left corner (below the LCD display). Select AC if you work in AC or DC if you work in DC. Incorrect selection of this switch will lead to errors in your experiment results.
The Oscilloscope was tested with a 1 KHz signal at the inputs as shown has low intensity, no further test done.
The DC 0 to 30 VDC with Centre Tap has been tested on a DMM.
Circuitmate DMM 15B has been tested for DC Current, Voltage and Resistance.
