58" tbl 10HP spdl hercules rfv-m vertical mill, geared
58" Tbl 10HP Spdl Hercules RFV-M VERTICAL MILL, Geared
58" Table 10HP Spindle Hercules RFV-M VERTICAL MILL, Geared Head, Feeds & Rapids, #50 Taper,
MOREY (HERCULES)/ROSENFORS VERTICAL MILL
MODEL: RFV-M S/N: 707 MFG: 1968
TABLE SIZE ...................................... 58" X 12"
LONGITUDINAL TABLE TRAVEL ............................. 35"
CROSS TABLE TRAVEL ................................ 12-3/4"
VERTICAL TABLE TRAVEL ..............................16-3/4"
HEAD VERTICAL TRAVEL ................................... 4"
MAXIMUM DISTANCE SPINDLE NOSE TO TABLE ............ 19-1/4"
FEED RANGE LONGITUDINAL & CROSS (16) ......... 1/2 - 35 IPM
FEED RANGE VERTICAL KNEE (16) ................ 1/4 - 17 IPM
SPINDLE TAPER ..................................... #50 STD
SPINDLE SPEEDS (36) ......................... 39 - 2000 RPM
SPINDLE QUILL FEEDS (4) ........ .0025, .005, .01 & .02 IPR
APPROXIMATE WEIGHT .............................. 6,500 LBS
