Agilent 81134A 15MHZ-3.35GHZ 2CH pulse patterngenerator
Agilent 81134A 15MHz-3.35GHz 2ch Pulse Pattern Generator
Internal Clock Generation; Frequency range:15MHz to 3.35GHz,
Resolution:1Hz,Accuracy:50ppm,JitterRandom:<4ps RMS, 2 channel,Delay:-5ns to 230ns,resolution:1ps,
Accuracy:+-20ps,Width range:100ps to period -100ps, Resolution:1ps,Accuracy:+-40ps,
Duty Cycle:0.15% to 99.85%, Channel Output Levels; Amplitude:5mV to 2.00V,Level Window:-2.00V to 3.00V,
Resolution:10mV,Accuracy:2%+-20mV,Impedance:50ohm,
Memory Depth:8kBit par Channel,Data Format:RZ/NRZ/R1, PRBS:2n-1,n=5,6,7,8,9,10,11,12,13,14,15,23,31,
General Information; EMC:Class A, Power:100 to 240Vac;Max 200VA;47Hz to 63Hz,
Size:145mm-426mm-553mm,Weight:14.8kg
Accessory : Rackmount kit ,CD-ROM(Driver,Document,IO Libraries),USB cable
