Mazak M4 1500 cnc lathe 22" swing 60" between centers
For Sale Mazak M-4 1500 CNC Lathe
SPINDLE TAPER & CENTER: A.S.T. 350 X MT NO. 5
SPINDLE SPEEDS: FULL AUTOMATIC NON-STEP
RANGE OF SPINDLE SPEEDS: 5 TO 2200 RPM
TYPE OF TURRET: 8D + 6B INTERCHANGEABLE REAR TURRET
TURRET TRAVEL-X AXIS: 21-21/32"
TURRET TRAVEL-Z-AXIS: 60-5/16"
RAPID TRAVERS SPEED: X AXIS- 400 IPM Z AXIS- 470 IPM
DIA. OF TAILSTOCK SPINDLE: 3-11/32"
STROKE OF TAILSTOCK SPINDLE: 5"
TAILSTOCK SPINDLE CENTER: MT NO. 4
Weight, Approximate: 12760 Lbs.
Issues: The videos below show that it is in working condition. It currently is under power and you can see it. When we got it the tool changer was working. During the videos, the machine was hanging up on the M39 code and would not cycle.
A parts lathe is also available. The same model lathe. Most of the parts are on it for an additional $2000.
The front slide doors are not shown, but we have them.
