Insulation machine blower
The 2400 series machine from provides an economical, high production machine with low power requirements and reduced weight/size in your truck/trailer system. The simple design and minimal moving parts provide a machine that is low maintenance and easy to repair. The most effective cost vs production machine in the industry.
All-Fiber, Wall Spray, Attic Blow Machine
Features of the CM 2400 Insulation Machine
* Large 11 cu./ft. hopper capacity fiber storage. ( 22 cu./ft with hopper extension)
* Stainless slide-gate control provides precise control of fiber.
* High quality powder coating provides a long lasting corrosion resistant finish.
* Modular design with see-thru access panels for quick troubleshooting and maintenance.
* Slow speed positive feed scalping augers extend component life, while increasing safety.
* Large 12" X 12" quick release airlock is a durable, easily serviced component.
* High speed stainless shredder maximizes fiber conditioning, coverage, and production.
* High torque (1250 in./lb.) motor/reducer drive provides surplus power
* #50 chain and hardened sprockets, are rugged, corrosion resistant, and positive driving.
* Two integrally mounted 3-stage blowers w/check valve protection, outside air and reduced filter
maintenance. (optional four blower or P.D. blower)
* Safety Features: kill switch and manual controls promote increased operator safety and quick
* Manual thermal overload protection of all motors and electrical components.
* Deluxe voltmeter for quick electrical diagnostics.
42 inch L x 22 inch W x 48 inch H
12 inch long x 12 inch diameter airlock
3 inch output for blowing hose
Blowers 4, 3 stage or 5hp positive displacement blower
