Jet/asian 20" step-pulley drill press jdp-20MF manual
20-inch Step-Pulley Drill Press JDP-20MF
This is a reproduction, not a photocopy, of an original JET JDP-20MF 20-inch Step Pulley Drill Press Instructions and Parts Manual. This manual contains general safety instructions, operation instructions, assembly instructions, adjustments, maintenance, lubrication, and a complete set of exploded view diagrams of the parts with description. Please read index below.
General Safety Instructions.........2
Additional Safety Rules.............3
Specifications......................4
Electrical Requirements.............5
Getting to Know Your Drill Press....6
Assembly Instructions...............7
Installing Chuck....................8
Removing Chuck & Arbor............8-9
Depth Stop..........................9
Spindle Speeds......................9
Tensioning Belt..................9-10
Return Spring Adjustment...........11
Basic Operational Hints............11
Lubrication........................11
Electrical Breakdown...............12
Parts Breakdown....................13
Parts List......................14-15
