> 23" x 16" y matsuura MC600V vertical machining center,
23" x 16" y matsuura MC600V vertical machining center,
23" X 16" Y Matsuura MC600V VERTICAL MACHINING CENTER,
23" X Axis 16" Y Axis Matsuura MC600V VERTICAL MACHINING CENTER, Yasnac MX-3 Control
MATSUURA MC600-V CNC VERTICAL MACHINING CENTER
TABLE DIMENSIONS......................... 15.7" X 34.6"
MAXIMUM TABLE CAPACITY................... 880 LBS.
X-AXIS TRAVEL............................ 23.62"
Y-AXIS TRAVEL............................ 16.14"
Z-AXIS TRAVEL............................ 18.5"
DISTANCE FROM TABLE TOP TO SPINDLE NOSE.. 5.9"-24.4"
DISTANCE FROM TABLE CENTER TO COLUMN..... 9.25" - 25.39"
AUTOMATIC TOOL CHANGER................... 20 ATC
SPINDLE SPEEDS, GEARED DRIVE (2 STAGES).. 30-7000 RPM
SPINDLE TAPER............................ BT40
RAPID FEEDRATE (X & Y,Z)................. 590,472 IPM
CUTTING FEEDRATE......................... .01" - 196"
MAXIMUM TOOL WEIGHT...................... 17.6 LBS.
MAXIMUM TOOL LENGTH...................... 11.8"
