Programmable dc power supply 32V 5A lab grade HY3005DP
Programmable DC Power Supply 32V 5A Lab Grade HY3005DP
For sale is a brand new lab grade regulated programmable DC power supply from Quakko, Model number HY3005DP. The output of this highly stable, high quality DC power supply is continuously adjustable at 0-32V DC and 0-5A. With its full digital control and 5 memory settings, it's extremely easy set up the output you want and repeat the settings you use regularly. What's more, you can use the USB interface and software that comes with the unit to program a waveform, essentially use this power supply as a arbitrary waveform generator. The unit comes with very bright LED displays, providing accurate readout for the voltage and current values. This unit has toggle switch at the back that allows you to operate it in 110V AC or 220V AC. Retails well over $400. Please email us with any questions, our hard-working staff will answer every email in no time!
* Can output constant Voltage (CV), Current CC, or programmed output in arbitrary waveform
* Low ripple and output noise
* OVP over-voltage protection / OCP over-current protection / OTP over-temperature protection
* 5 Memories of voltage and current settings
* 5 Memories of programmable waveform outputs
* Includes a set of test leads, software disc, USB cable, and power cord
* Adjustable outputs: 0-32V and 0-5A
* Input voltage: 110V AC and 220V AC switchable
* Line regulation: CV <= 0.03% + 5 mV, CC <= 0.05% + 2 mA
* Load Regulation: CV <= 0.1% + 5mV, CC <= 0.2% + 5 mA
* Ripple noise: CV <= 2 mV RMS, CC <= 1 mA RMS
* Protection: Over Voltage Protection (OVP), Over Current Protection (OCP), Over Temperature Protection (OTP),
* LCD reading accuracy: +/-0.1% + 2 digits for voltage and +/-0.5% + 5 digits for current
* Voltage Response time: <3 ms (up or down)
* Environment: 0-40C, relative humidity < 80%
