Allen bradley guard master safe shield light curtain
Allen Bradley Guard Master Safe Shield Light Curtain NR
Allen-Bradley Guard Master Safe Shield Light Curtain
It is possible to connect up to three segments in a cascaded configuration, with each of these segments having the advanced features individually programmed. Cable lengths between segments can be up to a maximum of three meters.
A communication cable is required to link your laptop to the SafeShield s transmitter and receiver, allowing the programming and configuration of your system. Password protection assures that once a system is configured, it is securely stored in the system s memory and is accessible only to authorized personnel.
This versatile safety light curtain system provides maximum flexibility in solving simple to complex machine guarding applications.
* Sturdy modular construction
* Universal application possibilities
* Control-reliable solid-state outputs
* State of the art microprocessor technology with custom-designed ASICs (Application Specific Integrated Circuits)
* Easy assembly and alignment
* Quick-disconnect M23 style connectors
* Long scanning range and high resolution
* Dimensions: 40.5"L x 1.5"W x 2"H
* Small housing cross section: 40 mm x 48 mm (1.57 in x 1.77 in)
* Possibility to cascade up to three sensors (to prevent personnel from standing between protective field and the point of operation)
* Construction in compliance with EN 61496 Parts 1 & 2
* Resolution (object sensitivity) 14 mm/30 mm
* The optical axis (center of window) is marked on the end cap.
* Fixed blanking, floating blanking
* Reduced resolution, beam coding
