Ametek chatillon dfs-250G digital force gage
AMETEK/CHATILLON DFS-250G DIGITAL FORCE GAGE
This compact, easy-to-use force gauge is designed for basic and complex applications. Ideal for handheld or test stand applications, the DFS may be equipped with integral loadcells or smart remote sensors for load measurement or torque measurement.
Measurement accuracy is better than 0.1% full scale. A large, easy-to-read, high resolution dot matrix LCD display supports a variety of standard gage functions including normal and peak readings, high/low limits, setpoints, pass/fail results, statistical results, load averaging, load comparisons, % and sharp break detection, loadcell actuation and direction. Loads are displayed in ozf, gf, lbf, kgf and N units. The display can be inverted and displayed results may be hidden from the operator.
The DFS gage comes standard with an RS-232 cable, carrying case, battery adapter/charger, stationary hook, point, chisel and notch testing accessories and NIST Certificate of Calibration with data.
NOTE: The DFS gage replaces the DFGS and DFA Series.
* Accuracy: +/-0.1% of full scale
* Data Sampling Rate: 5000 Hz
* Peak Capture Rate: 5000 Hz
* Overload Protection: 150% full scale
* Automatic Shut Down: Configurable time. May be disabled.
* Outputs: RS-232, Mitutoyo (Digimatic) and +2Vdc analog
