Motorola LM2935T low dropout dual voltage regulator
Motorola LM2935T Low Dropout Dual Voltage Regulator
The LM2935 is a dual positive 5.0 v low dropout voltage regulator designed for standby power systems. The main output is capable of supplying 750 mA for microprocessor power and can be turned "on" and "off" by the switch/reset input. The other output is dedicated for standby of the volatile memory, and is capable of supplying up to 10 mA loads. The total device features a low quiescent current of 3.0 mA or less when supplying 10 mA from the standby output.
* Two regulated 5.0 V outputs
* Main Output Current in Excess of 750 mA
* On/Of Control of Main Output
* Standby Output Current in Excess of 10 mA
* Low Input/Output Differential of Less than 0.6 V at 500 mA
* Short Circuit Current Limiting
* Low Voltage Indicator Output
* Designed for Automotive Envioronment Including
* Reverse Transient Protection
* Economical 5-Lead TO-220 Package with 2 Optional Leadforms
More specs: http://www.datasheetcatalog.org/datasheet/motorola/LM2935TV.pdf
245 available. Item discount available for multiple quantity. Email for details.
