Square d 9007C54A2 9007 C54A2 heavy duty limit switch
SQUARE D 9007C54A2 9007 C54A2 HEAVY DUTY LIMIT SWITCH
New, unused w/out box or papers
Operating Torque/Force: 4 Inch-Pounds
Actuator Action: Spring Return - Low Differential
Differential Travel: 2 Degrees
Approvals: UL Listed File Number E42259 CCN NKCR - CSA Certified File Number LR25490 Class 3211-03 - CE Marked
Connection Type: Conduit Entrance (0.5 Inch NPT)
Contact Configuration: 1 N.O./1 N.C.
Contact Rating: NEMA A600/Q600
Contact Material: Silver Alloy
Contact Operation: Snap Action
Contact Form: Form Z - SPDT-DB
Enclosure Rating: NEMA 1/2/4/6/6P/12/13
Operating Temperature Range: -20 to 185 Degrees F
