Siecor corning sm ots 120 / 304 fiber loss test set pm
* Siecor OTS-120 Optical Power Meter
* Siecor OTS-304XD-52 Optical Light Source
Siecor Singlemode Fiber Optic Loss Test Set
Siecor OTS-120 Optical Power Meter & Siecor OTS-304XD-52 Optical Light Source
Test 1310nm & 1550nm Wavelengths!
The OTS-300 Express Series includes intelligent, versatile optical meters, sources, and testers that simultaneously test and store dual wavelength attenuation measurements. The synchronized meter and source alternates between wavelengths to continually update the displayed data. This process cuts testing time in half and prevents costly errors from mismatched source and meter wavelengths. At the press of a button, dual wavelength results are stored and the next fiber measured. These test sets are used during installation, system qualification, and maintenance. The combination of practical features, simple operation, field performance, and rugged design make them perfect for virtually all fiber optic testing environments from multimode LAN to single-mode telephony and CATV.
Designed for the user, the OTS-300 Series provides quick, intuitive operation through a simple keypad and backlit graphic display with adjustable, temperature-compensated contrast. The power meters feature selectable resolution that optimizes use for both field (0.1 dB) and production or lab environments (0.01 dB). Detection of 2 kHz pulsed tone via both audible and visual indication allows versatile continuity testing and fiber tracing. Both the meters and the sources can be used with compatible OTS-311D and OTS-312XD testers to provide the same intelligent testing features.
The OTS-300 Express meters and testers make calibrated measurements at 850, 1300, 1310, and 1550 nm from +3 to -70 dBm using a high-performance InGaAs detector that minimizes reflection effects. A powerful microcontroller performs a self-test each time the unit is powered on to ensure reliable measurements.
OTS-300 Express sources and testers are available with a single port 850/1300 nm LED for multimode testing and a single port 1310/1550 nm laser for single-mode testing. The most versatile source is the OTS-3MDSD with four wavelengths. It incorporates a dual LED and a dual laser. The OTS-310 meter combined with the OTS-3MDSD creates a complete all-purpose test kit for multimode and single-mode applications.
The rugged ABS housing and elastomeric holster,weatherresistant membrane keypad, and -18 to +50 C operating temperature enable the OTS-300s to be used wherever there is fiber. Internal RF shielding protects from external error-causing interference. The three-way powering provides uninterrupted operation by automatically switching between the internal rechargeable Ni-Cads, replaceable batteries, and AC power. A selectable automatic shut-off function extends battery life.
* Auto testing provides dual wavelength display and storage that cuts testing time in half
* Eliminates field paperwork - stores up to 900 dual wavelength measurements and 50 jobs (files)
* Four-wavelength source: 850/1300 nm LED and 1310/1550 nm laser
* Dual wavelength 850/1300 nm and 1310/1550 nm sources and testers
* Emits and detects 2 kHz tone for detection, continuity, and tracing
* Selectable 0.1/0.01 dB resolution
* Reliable InGaAs performance for +3 to -70 dBm (standard range) and +20 to -60 dBm (CATV range)
* Flexible three-way power: AC, internal rechargeable battery, replaceable alkaline battery
* Backlit, easy-to-read display
* Wide operating temperature range of -18 to +50 C
-8 dBm coupled into 9/125 m fiber
Connector Type (Dedicated) Single Output
850, 1300, 1310, 1550, 1625 nm
0.1 dB @ +20 to -50 dBm (1300-1625 nm)
0.1 dB @ +20 to -40 dBm (850 nm)
