15" x 18"cc leblond regal engine lathe - well tooled
15" x 18"cc LEBLOND REGAL ENGINE LATHE - WELL TOOLED
15" x 18" LEBLOND ENGINE LATHE
MODEL: 15" REGAL, S/N: 2C-1114 NEW: 1960
SWING OVER BED .................... 15-1/2"
SWING OVER CROSS SLIDE ............ 9-1/2"
DISTANCE BETWEEN CENTERS .......... 18"
SPINDLE NOSE ...................... L-00
HOLE THRU SPINDLE ................. 1-11/32"
WIDTH OF BED ...................... 12-3/16"
SPINDLE SPEED RANGE (12) .......... 45 - 1800 RPM
LONGITUDINAL FEED RANGE (48) ...... .0018" - .106" IPR
CROSS FEEDS HALF THE VALUES OF LONGITUDINAL
THREADING RANGE ENGLISH (48) ...... 4 - 224 TPI
TAILSTOCK SPINDLE TRAVEL .......... 5"
TAILSTOCK SPINDLE TAPER ........... #3 MT
APPROX WEIGHT ..................... 2,200 LBS
APPROX DIMENSIONS ................. 60"L x 34"W x 45"H
QUICK CHANGE TOOLPOST WITH HOLDERS
COOLANT SYSTEM WITH REMOVABLE CHIP PAN
MACHINE IS PRESENTLY WIRED FOR 220 VOLT
INSPECT UNDER POWER IN OUR NEW JERSEY WAREHOUSE
CONDITION: **** EXCELLENT ****
