New lot 8 hokuyo dms-HB1-Z09 optical sensor transceiver
LOT 8 HOKUYO DMS-HB1-Z09 OPTICAL SENSOR TRANSCEIVER NEW
HOKUYO OPTICAL DATA TRANSMISSION DEVICE
The SEMI E84 standard as outlined provides the scope for which the optical PI/O sensors must comply as it relates to the communications associated with material handoff operations. As a global leader in optical PI/O solutions, Hokuyo provides key products with their DMS and DMG series.
8-bit optical transceiver that include DMS-HB1-V and DMS-HB1-Z versions
Extends parallel I/O communications associated with the material
handoff operations between active and passive equipment
Status Indicator LEDs for Input, Output, Go signals and Power
Units equipped with 2-meter, 5-meter or custom cable assembly lengths.
Units equipped with 25-pin D-sub connector wired to SEMI E84 pin assignments.
Standard Units without 25-pin D-sub (used for customized assembly),
Complete Assembly with 2-meter cable and 25-pin D-sub connector, and
Complete Assembly with 5-meter cable and 25-pin D-sub connector.
